Franz Baudenbacher, Tilmann Schober, Jose Renato Pinto, Veniamin Y. Sidorov, Fredrick Hilliard, R. John Solaro, James D. Potter, Björn C. Knollmann
Published in Volume 118, Issue 12
J Clin Invest. 2008; 118(12):3893–3903 doi:10.1172/JCI36642
Abstract | Full text | PDF | Supplemental material
Options: View larger image (or click on image)
Medium
Figure 3
Ca2+-sensitizing TnT mutants increase the spatial dispersion of electrical activation during fast pacing and create a substrate for functional reentry.

(A) Examples of isochronal activation maps of mouse hearts at different pacing rates from an R278C and an I79N heart. Hearts were stained with the voltage-sensitive fluorescent indicator di-4-ANEPPS, and epicardial images were obtained from the anterior aspect of the left ventricle at the PCL indicated above each image. (BD) Effect of TnT mutants on CV and CV dispersion. CVs were calculated along 10 equally spaced radial lines from the stimulus side (red circle) near the apex as shown in B and were averaged for each heart. CV dispersion was quantified as the SD of the 10 CV determinations and expressed as percentage of average CV per heart. (C) Average CV decreased with shorter PCLs (shorter PCLs result in faster pacing) in all groups regardless of genotype. (D) Spatial CV dispersion was significantly increased in Ca2+-sensitized transgenic hearts. *P < 0.05, **P < 0.01 between groups, by 2-way ANOVA with repeated measures; I79N, n = 7; F110I, n = 7; R278C, n = 5. (E) Optically recorded repetitive activation pattern during VT. Fluorescence difference images of successive frames taken from the anterior left ventricle epicardial surface of an I79N heart during sustained VT. The time stamp is referenced to the first image. The activation pattern during VT shows typically a spiral wave rotating around a fixed center, forming a reentrant excitation (see also Supplemental Video 1).
