Kory J. Lavine, Attila Kovacs, David M. Ornitz
Published in Volume 118, Issue 7
J Clin Invest. 2008; 118(7):2404–2414 doi:10.1172/JCI34561
Abstract | Full text | PDF | Supplemental material
Options: View larger image (or click on image)
Medium
Figure 4
Loss of cardiac HH signaling results in cell death and tissue hypoxia.

(AD) TUNEL staining revealed increased apoptosis in Smomer (C) and Smomer,sm22 (D) hearts compared with control (A) and Smosm22 (B) hearts. TUNEL-positive cardiomyocytes (black arrows) and coronary endothelial cells (black arrowheads) were observed. (EH) Immunostaining of control (E), Smosm22 (F), Smomer (G), and Smomer,sm22 (H) hearts with Abs against active caspase-3, demonstrating expression in cardiomyocytes (black arrows) and coronary endothelial cells (black arrowheads) in Smomer and Smomer,sm22 hearts. (IL) Hypoxyprobe-1 staining of control (I), Smosm22 (J), Smomer (K), and Smomer,sm22 (L) hearts showing hypoxic cardiomyocytes (black arrows) in Smomer and Smomer,sm22 hearts. Original magnification, ×400.
