Xin-Ming Shen, Taku Fukuda, Kinji Ohno, Steven M. Sine, Andrew G. Engel
Published in Volume 118, Issue 5
J Clin Invest. 2008; 118(5):1867–1876 doi:10.1172/JCI34527
Abstract | Full text | PDF
Options: View larger image (or click on image)
Medium
Figure 9
Structural model of the AChR α and δ subunits and mutant cycle analyses.

(A) An enlarged view of the coupled intersubunit residues αY127 and δN41 in the structural model of the Torpedo AChR (Protein Data Bank code 2BG9). (B) A mutant cycle for the mutations αY127T, δL42P, and εL40P. Single-channel currents correspond to each AChR elicited by 100 μM ACh, as in Figure 6. Changes in gating free energy along each limb of the cycle are shown, and the overall coupling free energy (ΔΔGint) in units of kcal/mol computed from –RTln[(θwwθmm) / (θwmθmw)], where θ (β/α) is a gating equilibrium constant for diliganded receptors for wild-type, single-mutant, or double-mutant AChRs (Table 4). Horizontal bar indicates 20 ms for wild-type and 100 ms for mutant AChRs. Vertical bar indicates 5 pA. (CE) Mutant cycles for the indicated mutations are shown, as described in B.
