Jormay Lim, Martin Balastik, Tae Ho Lee, Kazuhiro Nakamura, Yih-Cherng Liou, Anyang Sun, Greg Finn, Lucia Pastorino, Virginia M.-Y. Lee, Kun Ping Lu
Published in Volume 118, Issue 5
J Clin Invest. 2008; 118(5):1877–1889 doi:10.1172/JCI34308
Abstract | Full text | PDF
Options: View larger image (or click on image)
Medium
Figure 9
Opposite effects of Pin1 overexpression on peripheral neuropathies of WT tau and Tg P301L tau mice.

Analysis of semithin sections of the sciatic nerves revealed presence of degenerating axons (arrows) often engulfed by macrophages (C, inset) in 18-month-old Tg WT tau mice (C) but not in the age-matched Pin1/tau double-Tg mice (D), non-Tg WT (A), or Pin1 Tg mice (B). On the contrary, few neuronal lesions were detected in sciatic nerves (E) of 7-month-old Tg P301L tau mice, while overexpression of Pin1 and P301L tau caused massive neurodegeneration in the sciatic nerves of the age-matched double-Tg mice. (F). Arrowheads point to demyelinated axon, and arrows point to macrophages clearing myelin debris. Scale bars: 20 μm.
