Nicolas Christoforou, Ronald A. Miller, Christine M. Hill, Chunfa C. Jie, Andrew S. McCallion, John D. Gearhart
Published in Volume 118, Issue 3
J Clin Invest. 2008; 118(3):894–903 doi:10.1172/JCI33942
Abstract | Full text | PDF | Supplemental material
Options: View larger image (or click on image)
Medium
Figure 6
In situ hybridization.

Whole-mount in situ hybridization analysis for genes identified by microarray expression analysis to be upregulated in the mES cell–derived CPCs. Hybridization was done on mouse embryos isolated on E7.5, E8.5, and E9.5. Genes analyzed are Cap2, Zfp69, 3632451O06Rik, Pcdh12, and 4631423F02Rik. Arrowheads indicate the cardiac crescent; arrows indicate expression in the lateral periphery of the common atria and left ventricle. H, heart; OFT, outflow tract.
