Alexandre S. Basso, Dan Frenkel, Francisco J. Quintana, Frederico A. Costa-Pinto, Sanja Petrovic-Stojkovic, Lindsay Puckett, Alon Monsonego, Amnon Bar-Shir, Yoni Engel, Michael Gozin, Howard L. Weiner
Published in Volume 118, Issue 4
J Clin Invest. 2008; 118(4):1532–1543 doi:10.1172/JCI33464
Abstract | Full text | PDF | Supplemental material
Options: View larger image (or click on image)
Medium
Figure 3
Fullerene ABS-75 treatment halts oxidative injury, blocks CCL2 production by astrocytes, and reduces CD11b infiltration into the spinal cord of secondary progressive EAE mice.

(A) CD11b staining revealed large numbers of CD11b+ cells infiltrating the ventral column (arrows) of vehicle-treated control animals, which was almost absent in mice that received the fullerene ABS-75 treatment. Original magnification, ×200. Quantification confirmed reduced CD11b+ cells infiltrating the spinal cord in ABS-75–treated animals with progressive EAE. P < 0.007; Student’s t test, mean ± SD. (B) Intense staining for nitrotyrosine (stained red; white arrows) in the spinal cord of vehicle-treated mice after disease progression indicated occurrence of oxidative injury, which was absent in ABS-75–treated animals. The presence of hyperreactive astrocytes (GFAP, stained green, yellow arrows) was associated with oxidative injury in vehicle-treated animals. Original magnification, ×200. (C) CCL2 staining demonstrated a large number of cells expressing CCL2 in the spinal cord of control animals after disease progression, whereas CCL2-positive cells were virtually absent in animals treated with fullerene ABS-75. Original magnification, ×100. (D) Triple staining performed on the spinal cord of control mice revealed high CCL2 expression (green) by astrocytic processes (GFAP, shown in red) in inflamed (blue nuclei of infiltrating cells) regions of the white matter. This demonstrates that in control animals, infiltration of inflammatory cells is associated with astrocytic expression of CCL2. Original magnification, ×400.
